Laravel JWT Auth with Vue.js

This post documents using Laravel to build JSON Web Token based authentication with a Vue.js user interface.

A fresh install of Laravel 5.2 for local development is required. Head over to the Laravel 5.2 docs to get setup with Composer and Laravel as needed. This post contains some info on how I installed Laravel 5.2 on Windows. Once Laravel 5.2 is installed, the database created and the .env file updated to connect to it, run the migration to create the users table.

php artisan migrate

User Model

One of the first things I like to do is create a Models folder and move the User model into it. To organize models within their own directory, start by creating a folder named Models in the app directory and move the User model into it.

mkdir app/Models

mv app/User.php app/Models

Edit app/Models/User.php, change the App namespace to App\Models.

User.php
<?php

namespace App\Models;

use Illuminate\Foundation\Auth\User as Authenticatable;

class User extends Authenticatable
{
    ...

  • Throughout this tutorial you will encounter an ellipsis … in the code examples. These are not a part of the code and are there only to denote code that is being skipped and not applicable to the example. To view the entire file, examine the source code.

Edit, config/auth.php. Update the authentication drivers user provider for the App\Models\User namespace change as follows.

auth.php
'providers' => [
    'users' => [
        'driver' => 'eloquent',
        'model' => App\Models\User::class,
    ],

    ...

Laravel Elixir Vueify

Using NPM, install the dependencies including laravel-elixer and gulp that should already be defined in the package.json file.

npm install

Install the Laravel Elixir and the Browserify Vueify plugin wrapper, laravel-elixir-vueify. This node package also includes Vue.js.

For Laravel Elixer 5
npm install laravel-elixir-vueify@1.0.6 --save-dev

Laravel Elixir is a build tool wrapper for Gulp. To use laravel-elixir-vueify, require laravel-elixir-vueify and update the elixir call with mix.browserify in the gulpfile.js as follows.

REPLACE
elixir(function(mix) {
    mix.sass('app.scss');
});
WITH
require('laravel-elixir-vueify');

elixir(function(mix) {
    mix.browserify('app.js');
    mix.sass('app.scss');
});

Create a resources/js folder for the JavaScript.

mkdir resources/assets/js

Create a resources/js/app.js JavaScript file.

touch resources/assets/js/app.js

Test the gulp build. A browserified app.js file that includes an external source map file should get compiled and written to public/js/app.js. The pre-existing app.scss Sass file should also get compiled.

gulp
Default Gulp task output
Default Gulp task output

Vue Router and Components

Install the router for Vue.js.

npm install vue-router --save-dev

Create a resources/assets/components folder and add an empty App.vue, Dashboard.vue, Home.vue, Register.vue and Signin.vue component.

mkdir resources/assets/components

touch resources/assets/components/App.vue

touch resources/assets/components/Dashboard.vue

touch resources/assets/components/Home.vue

touch resources/assets/components/Register.vue

touch resources/assets/components/Signin.vue

Add the following code to the empty App.vue file which will be the base layout component.

App.vue
<template>
    <div class="panel panel-default">
        <div class="panel-heading">
            <nav>
                <ul class="list-inline">
                    <li><a v-link="{ name: 'home' }">Home</a></li>
                    <li class="pull-right">
                        <a v-link="{ name: 'register' }">Register</a>
                    </li>
                </ul>
            </nav>
        </div>
        <div class="panel-body">
            <router-view></router-view>
        </div>
    </div>
</template>

Add the following code to the empty Home.vue file. The content in this template will populate the App.vue router-view element by default.

Home.vue
<template>
    <h1>Laravel 5</h1>
</template>

Add the following code to the empty Register.vue file for the user account creation form.

Register.vue
<template>
    <div class="alert alert-danger" v-if="error && !success">
        <p>There was an error, unable to complete registration.</p>
    </div>
    <div class="alert alert-success" v-if="success">
        <p>Registration completed. You can now sign in.</p>
    </div>
    <form autocomplete="off" v-on:submit="register" v-if="!success">
        <div class="form-group" v-bind:class="{ 'has-error': error && response.username }">
            <label for="name">Name</label>
            <input type="text" id="name" class="form-control" v-model="name" required>
            <span class="help-block" v-if="error && response.name">{{ response.name }}</span>
        </div>
        <div class="form-group" v-bind:class="{ 'has-error': error && response.email }">
            <label for="email">E-mail</label>
            <input type="email" id="email" class="form-control" placeholder="gavin.belson@hooli.com" v-model="email" required>
            <span class="help-block" v-if="error && response.email">{{ response.email }}</span>
        </div>
        <div class="form-group" v-bind:class="{ 'has-error': error && response.password }">
            <label for="password">Password</label>
            <input type="password" id="password" class="form-control" v-model="password" required>
            <span class="help-block" v-if="error && response.password">{{ response.password }}</span>
        </div>
        <button type="submit" class="btn btn-default">Submit</button>
    </form>
</template>

Add the following code to the empty app.js file to require vue, the vue-router, import vue components, setup the router. Export Vue and the router to allow modules to import them.

app.js
var Vue = require('vue');
var VueRouter = require('vue-router');

import App from '../components/App.vue';
import Dashboard from '../components/Dashboard.vue';
import Home from '../components/Home.vue';
import Register from '../components/Register.vue';
import Signin from '../components/Signin.vue';

Vue.use(VueRouter);

export default Vue;
export var router = new VueRouter

router.map({
    '/': {
        name: 'home',
        component: Home
    },
    '/register': {
        name: 'register',
        component: Register
    }
});

router.start(App, '#app');

Web Page

Edit the resources/views/welcome.blade.php template.

Replace the entire contents of the file with this markup.

welcome.blade.php
<!DOCTYPE html>
<html>
<head>
    <meta charset="utf-8">
    <meta name="csrf-token" content="{!! csrf_token() !!}">
    <title>Laravel</title>

    <link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" integrity="sha384-BVYiiSIFeK1dGmJRAkycuHAHRg32OmUcww7on3RYdg4Va+PmSTsz/K68vbdEjh4u" crossorigin="anonymous">

</head>
<body>
    <div class="container">
        <div id="app"></div>
    </div>
    <script src="/js/app.js"></script>
</body>
</html>

Now is a good time to test that everything builds and you have a Bootstrap styled page with with links to Home and Register in a horizontal navigation bar and a content panel under it with “Laravel 5” heading text. Select the Register link to diplay the form in the content panel.

gulp
Laravel JWT Auth Vuejs User Registration Form
New User Registration Form

The next page covers Vue Resource for request handling, Form Request Validation, API authorization with JWT Auth, User endpoint and Sign in.


Laravel Install on Windows IIS

This post documents installing PHP 7, PHP Manager and Laravel 5.3 on Internet Information Services (IIS) Manager version 10 which ships with Windows 10 Pro. This Laravel Installation will also be configured to connect to a SQLite database.

Internet Information Services (IIS) Manager

IIS needs to be installed, open the Windows Features dialog to check the installation. One way to do this is by selecting the start button and type Windows Features to bring up a list where “Turn Windows features on or off” can be selected. Another way to get to this Control Panel app is Windows + R key combination and run appwiz.cpl. Turn Windows features on or off link should be in the upper left panel.

Windows Features - IIS and .NET Framework 3.5 enabled
Windows Features

Notice that under .NET Framework 3.5 that both Windows Communication Foundation features are enabled. This may be needed in order for a successful install of PHP Manager. Installation of PHP Manager for IIS requires .NET 3.5 to work properly.

PHP and PHP Manager

Install PHP 7 for Windows using the Microsoft Web Platform Installer. It’s an easy way to get both PHP and the PHP Manager installed and takes some of the guess work out of getting PHP up and running on Windows and IIS.

  • If PHP Manager Fails to install after confirming that .NET 3.5 is installed and enabled, this is likely due to the installer throwing an error when checking the IIS version. Change the W3SVC MajorVersion value to 7 (decimal) in the registry. After the install is completed, change the value back to 10. More info is available at the PHP Manager – Refuses to install for WTP10 view issue page.

Registry Editor - HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Services\W3SVC\Parameters
[HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Services\W3SVC\Parameters]

* YMMV, I am not responsible if you hose your system when editing the registry.

PHP Extensions

In the Internet Information Services (IIS) Manager, Open PHP Manager and select the Enable or disable an extension link. Ensure that the extensions needed for Laravel are enabled. If you want to be able to connect to a SQLite database, enable the php_sqlite3.dll PHP extension. The figure below shows the PHP extensions I have enabled for a working Laravel 5 installation.

PHP Extensions provide additional functionality to PHP runtime, such as database connectivity, caching, debugging and others. Use this feature to enable or disable PHP extensions and to configure PHP extensions settings.
PHP Manager – PHP Extensions

Composer for Windows

Download and run Composer-Setup.exe Windows Installer. The installer will download Composer and set up the PATH environment variable.

Using the Windows Command Prompt, make sure Composer for Windows is installed by running the composer –version command.

composer --version

Git for Windows

Git for Windows is needed so Composer for Windows can download packages. During the installation process, Adjusting your PATH environment, make sure the option, Use Git from the Windows Command Prompt is enabled.

Using the Windows Command Prompt, make sure Git for Windows is installed by running the git –version command.

git --version

Create Laravel Project

Bring up the Adminstrator Command Prompt. One way to do this is by selecting the start button and type command to bring up a list where “Command Prompt” can be selected. Right click on Command Prompt and select Run as administrator .

cd c:/intepub

composer create-project laravel/laravel laravel "5.3.*"

Add Website

Open Internet Information Services (IIS) Manager. Right click on the server and select Add Website. Fill out the form as follows:
Site name: Laravel
Application pool: DefaultAppPool
Physical path: C:\inetpub\laravel
Host name: laravel.win

Select “Test Settings” and then “OK” if successful.

Add Website
IIS – Add Website

Hosts Mapping

Since the Host name laravel.win was entered for the website, the hosts file needs to be updated. Open Notepad as an administrator. One way to do this is by selecting the start button and type Notepad to bring up a list where it can be selected. Right click on Notepad and select Run as administrator.

Select File | Open, or Ctrl + O and change the File type from Text Documents (*.txt) to All Files (*.*). Browse to C:\Windows\System32\drivers\etc and select the hosts file. Add an entry to map localhost to laravel.win as follows.

hosts
127.0.0.1   localhost
127.0.0.1   laravel.win

Laravel Storage Permissions

In File Explorer, right click on the storage folder in C:\inetpub\laravel and select Properties. Under the Security tab, grant full control of the storage folder to IUSR as shown in the figure below.

Properties Dialog - Security
Permissions for storage
Laravel web.config

Since IIS does not have an .htaccess file like Apache, create a web.config file in C:\inetpub\laravel\public as follows.

web.config
<configuration>
    <system.webServer>
        <defaultDocument>
            <files>
                <clear />
                <add value="index.php" />
                <add value="default.aspx" />
                <add value="Default.htm" />
                <add value="Default.asp" />
                <add value="index.htm" />
                <add value="index.html" />
            </files>
        </defaultDocument>
        <rewrite>
            <rules>
                <rule name="Imported Rule 1" stopProcessing="true">
                    <match url="^(.*)/$" ignoreCase="false" />
                    <conditions>
                        <add input="{REQUEST_FILENAME}" matchType="IsDirectory" ignoreCase="false" negate="true" />
                    </conditions>
                    <action type="Redirect" redirectType="Permanent" url="/{R:1}" />
                </rule>
                <rule name="Imported Rule 2" stopProcessing="true">
                    <match url="^" ignoreCase="false" />
                    <conditions>
                        <add input="{REQUEST_FILENAME}" matchType="IsDirectory" ignoreCase="false" negate="true" />
                        <add input="{REQUEST_FILENAME}" matchType="IsFile" ignoreCase="false" negate="true" />
                    </conditions>
                    <action type="Rewrite" url="index.php" />
                </rule>
            </rules>
        </rewrite>
        <httpErrors errorMode="Detailed" />
    </system.webServer>
</configuration>

Laravel SQLite Database

Create a SQLite database * in C:\inetpub\laravel\database. Edit C:\inetpub\laravel\.env database values to configure the database connection.

.env
DB_CONNECTION=sqlite
DB_HOST=127.0.0.1
DB_PORT=3306
DB_DATABASE=database/laravel.sqlite
DB_USERNAME=
DB_PASSWORD=

* DB Browser for SQLite is an open source, freeware tool used to create, design and edit SQLite database files.

Restart IIS

In an Administrative Command Prompt, restart IIS so all of the changes get applied.

iisreset /restart

In IIS, make sure that the Larvel web site has been started. If the W3SVC service is not running, it can be started with the following command.

net start w3sv

Once all is said and done, load http://laravel.win in a web browser. Laravel 5.3 default page should look similar to the screen shot below.

Laravel 5.3 Default Screen
Laravel 5.3

Installing Laravel on XAMPP

This post documents installing Laravel locally using XAMPP. When you are developing with Laravel on an older computer or one with limited resources, using XAMPP for your local PHP and MySQL development server works well on Windows.

Laravel PHP Requirements

This table shows the minimum PHP version requirements for the latest versions of Laravel.

Laravel PHP
5.3 5.6.4
5.1, 5.2 5.5.9
5.0 * 5.4

* PHP 7 not supported in this version

Head over to the Apache Freinds site to download the version of XAMPP that meets the minimum PHP requirements for the version of Laravel you are supporting. If you are developing in Laravel 5.2 currently and also want to be able to support Laravel 5.3, get the XAMPP version that includes PHP 7.

For Windows, I have xampp installed at the root directory on C:\ drive. here is the virtual hosts configuration I am using for Laravel. More information for setting up XAMPP on Windows.

httpd-vhosts.conf
<VirtualHost *:8080>
    DocumentRoot "C:/xampp/htdocs/laravel/public"
    ServerName laravel.dev
    ServerAlias www.laravel.dev
    SetEnv APPLICATION_ENV development
    <Directory "C:/xampp/htdocs/laravel">
        Options Indexes MultiViews FollowSymLinks
        AllowOverride All
        Order allow,deny
        Allow from all
    </Directory>
</VirtualHost>

Edit C:\Windows\System32\drivers\etc\hosts file, mapping laravel.dev hostname to 127.0.0.1 localhost IP address.

hosts
127.0.0.1   laravel.dev

Install Laravel

This example will install laravel 5.2 into C:/xampp/htdocs/laravel using Composer.

cd c:/xampp/htdocs

composer create-project laravel/laravel laravel "5.2.*"
